Distance between centers
250 mm
Spindle taper
MT 2
Taper of tailstock sleeve
MT 1
Travel of tailstock sleeve
25 mm
Weight approx.
39 kg
Center height
75 mm
Swing over bed
150 mm
Spindle bore
10 mm
Metric thread
(5) 0,5 - 1,25 mm
Inch thread
(5) 16 - 24 threads/1"
Machine dimension (W x D x H)
650 x 350 x 520 mm
Drilling capacity in steel
10 mm
Face mill capacity max.
20 mm
Distance spindle to column
105 mm
Spindle stroke
30 mm
Spindle speed, stepless
100 - 1000 / 100 - 2000 rpm
Motor power output S1 100%
0,15 kW / 230 V
Motor power input S6 40%
0,25 kW / 230 V
Speed range, stepless
100 - 2000 rpm
Mill head height adjustable
130 mm

Proficenter 250

1092097
Ask for the price and delivery time by phone

You can buy our products from our partner stores

Interested in a B2B partnership?

Contact us:

Description

Properties

  • Electronic, stepless adjustable drive
  • High-quality ball bearings guarantee high concentricity
  • User-friendly arranged control elements
  • Straightforward speed change
  • Inductive hardened, polished machine bed
  • Leadscrew features automatic feed
  • Milling attachment includes precise fine adjustment
  • Spindle with clamp device ensures accurate results

Standard accessories

  • 3-jaw chuck 80 mm
  • Chuck cover
  • 2-way tool post holder
  • Live center MT 1
  • Drill chuck 1 - 10 mm / B 12
  • Tools
