HWP 30
HWP 30
HWP 30
HWP 30
HWP 30
  • Online only
HWP 30
HWP 30
HWP 30
HWP 30
HWP 30

Width
1315 mm
Weight approx.
395 kg
Depth
805 mm
Height
2120 mm
Motor power
1,5 kW
Table width
325 mm
Forward speed
9,8 mm/sec.
Return speed
18,11 mm/sec.
Pressure force
30 to
Passage between stand
750 mm
Piston stroke
380 mm
Piston diameter
55 mm
Max pressure
221 bar
Max. working height
950 mm
Working speed
3,57 mm/sec.

HWP 30

1305855
Price €7,937.00 VAT incl.

Stock Quantity:
Kaunas Shop
not available
Central warehouse
not available
In Supplier store
(10 pcs)
Delivery terms:
FREE pick up wednesday, july 15 d., in the store, Raudondvario pl. 141, Kaunas (€0.00)
Weight: 395 kg.
We will deliver the product to you via: 5-11 w.d. Venipak (€40.99)
Weight: 395 kg.

Description

Properties

  • Ideal for assembly and straightening work, but also ideal for setting up tools, during load tests and for workpiece checks
  • Table height adjustment by means of chain and working cylinder
  • Piston feed either trough hand lever or sensitive hydraulic pump
  • Fast forward and return speeds for efficient work
  • Powerful workshop presses for craft and repair shops
  • Piston can be stopped in any position

Standard accessories

  • Pressure gauge
  • Height adjustable work table
  • Overload valve
