Elektrodai ESAB OK 67.70 - 2.5mm x 300mm / 1.7kg

WARRANTY

Classifications: Werkstoffnummer : 1.4459
Approvals: VdTÜV : 02424
Alloy Type: Austenitic CrNi
Welding Current: DC+, AC
Ferrite Content: FN 12-22
Coating Type: Acid Rutile
Packaging: 2.5mm x 300mm / 1.7kg
Diameter (Ø): 2.5mm

Brand

Elektrodai ESAB OK 67.70 - 2.5mm x 300mm / 1.7kg

Name: Elektrodai ESAB OK 67.70 - 2.5mm x 300mm / 1.7kg
Brand: ESAB
SKU: 1265588
Price: 41 EUR
Availability: PreOrder

Reference 1265588

Price €41.00 VAT incl.

‹

2.0mm x 300mm / 0.7kg

2.5mm x 300mm / 0.7kg

2.5mm x 300mm / 1.7kg

3.2mm x 350mm / 1.8kg

›

Stock Quantity:

Kaunas Shop
not available

Central warehouse
not available

In Supplier store
(5+ pcs)

Delivery terms:

FREE pick up monday, may 19 d., in the store, Raudondvario pl. 141, Kaunas (€0.00)

We will deliver the product to you via: 5-11 w.d. Venipak (€3.00)

We will deliver the product to you via: 5-11 w.d. Venipak pickup (paštomatas) (€2.50)

Description

Acid rutile MMA-electrode giving an over alloyed weld metal. Suitable for welding acid resistant stainless steels to mild and low alloyed steels. Also suitable for welding buffer layers when surfacing mild steel with acid resistant stainless steel weld metal.

Specifications

Approvals are based on factory location. Please contact ESAB for more information.

Typical Tensile Properties
Condition	Yield Strength	Tensile Strength	Elongation
ISO
As Welded	510 MPa	610 MPa	32 %

Typical Charpy V-Notch Properties
Condition	Testing Temperature	Impact Value
ISO
As Welded	20 °C	50 J
As Welded	-20 °C	35 J

Typical Weld Metal Analysis %
C	Mn	Si	Ni	Cr	Mo	N	Ferrite FN
0.02	0.6	0.8	13.4	22.5	2.8	0.09	18

Deposition Data
Diameter	Current	Voltage	Efficiency (%)	Fusion time per electrode at 90% I max	Deposition Rate
2.0 x 300.0 mm	40-60 A	26 V	58 %	48 sec	0.6 kg/h
2.5 x 300.0 mm	50-90 A	29 V	57 %	45 sec	0.9 kg/h
3.2 x 350.0 mm	60-120 A	27 V	59 %	61 sec	1.4 kg/h
4.0 x 350.0 mm	85-180 A	31 V	61 %	56 sec	2.0 kg/h
5.0 x 350.0 mm	110-250 A	30 V	59 %	64 sec	2.7 kg/h
