WARRANTY

  • 30 days return policy
  • 24 month product warranty
  • Free consultation
  • 30 days return policy
  • 24 month product warranty
  • Free consultation

Weight approx.
324 kg
Machine dimension (W x D x H)
2800 x 2900 x 1180 mm
Motor power output S1 100%
3,8 kW (5,1 HP)
Motor power input S6 40%
5,3 kW (7,2 HP)
Voltage
400 V
Dust extraction outlet
100 mm
Table size
800 x 380 mm
Table height
870 mm
Table extension
500 x 310 mm
Cutting length
2800 mm
Table enlargement
800 x 880 mm
Sliding table
2800 x 270 mm
Max. sawblade diameter
315 x 30 mm
Max. cutting height 90° / 45°
100 / 80 mm
Cutting width on rip fence
1200 mm
Speed main sawblade
4000 rpm
Speed scoring sawblade
5800 rpm
Scoring sawblade
90 x 20 mm
Square table with roller
880 x 580 mm

Formatinės pjovimo staklės Bernardo FKS 2800 Pro

1055989
€6,136.00
Tax included
Monthly payment from 150.94€

Stock Quantity:
In S01 store
not available
In S02 store
not available
In Supplier store
(5+ pcs)
Delivery terms:
NEMOKAMAI atsiimkite monday, january 6 d., parduotuvėje, Raudondvario pl. 141, Kaunas (€0.00)
Weight: 324 kg.
Prekę pristatysime Jums per: 5-11 d.d. Venipak (€40.99)
Weight: 324 kg.

Description

Properties

  • Important feature: Sawblade diameter 315 mm can be used when scoring unit is mounted
  • Solid square table with roller and telescopic arm guarantee high stability
  • Anodized aluminium sliding table available in three lengths
  • Powerful drive motor for constant cutting speed, even at cutting height of 100 mm
  • Mitre fence and downholder can be moved along entire table length
  • Amply sized work table and table extensions for cutting width up to 1200 mm come standard
  • Extractable telescopic fence (up to 2260 mm) mountable at front or rear of square table, steplessly tiltable from 90º to 45º
  • Aluminium parallel fence with micrometric fine adjustment and integrated magnifying glass
  • Solid saw unit guarantees precise work, free from vibrations

Standard accessories

  • Carbide sawblade 315 x 3,0 x 30 mm / 40T
  • Scoring sawblade 90 x 3,0 x 20 mm / 12T
  • Protective cover with dust extraction outlet
  • Connector hose with Y-piece
  • Mitre fence with eccentric holder
  • Mitre fence
  • End stop
  • Table extension
  • Table enlargement
  • Rip fence
  • Extractble telescopic fence
  • Stop with fine adjustment
  • Square table
  • Push handle
  • Push stick
  • Tools
